Pneumatic Marking Machine
The key advantage of pneumatic marking machines lies in their ability to create deep, permanent marks, forming indentations on metal and high-hardness materials that are highly resistant to wear. These machines are highly versatile and cost-effective; their portable models can be attached to the surfaces of large workpieces, allowing for flexible, on-site operation without the need to move heavy workpieces.
A pneumatic marking machine is a contact-type marking device that uses compressed air to drive the marking needle to perform high-frequency impacts. The system controls the marking needle to move along a preset trajectory in the X-Y plane while simultaneously performing high-frequency impacts under pneumatic pressure, thereby forming characters, graphics, or QR codes composed of dot matrices on the surface of the workpiece.
Even after the workpiece undergoes subsequent surface treatments such as painting, powder coating, electroplating, or blackening, the original deep markings remain clearly visible and may even become more prominent due to the filling effect of the coating.
Smart Controller
Designed to meet the demanding requirements of modern industry, this controller is suitable for any environment. The color touchscreen simplifies setup and comes standard with a wide range of features.
Advanced Communication
Equipped with various interfaces (USB, Ethernet, RS232), it can read data from MES systems and interact with selected MES data via custom software.
Data-Driven Insights
The controller panel and maintenance information allow you to directly monitor the machine’s status.
Quality and Precision
Designed to meet the most stringent standards, this system delivers high marking precision and superior quality. Its robust mechanical structure and high-precision guide rails ensure perfect needle alignment and repeatable marking accuracy.
Versatility
The marking head incorporates Precision Technology’s DDCTM (Dynamic Dot Control) technology, which automatically adjusts dot density based on the required marking size and depth.
DATAMATRIX QR Code Marking
The electromagnetic marking pen is equipped with a high-performance coil, making it particularly suitable for marking QR codes (Datamatrix, UID, QR codes, etc.). Stable and fast, it has proven its value in high-value-added applications across numerous demanding industries.
Compact
The ideal solution for small spaces, allowing you to easily integrate a marking system into your production line. Whether on a production line or a robotic arm, it can be easily installed in any orientation, significantly reducing installation time and costs.
Fast
Equipped with fast, high-precision linear guides, it delivers high-quality markings at high speeds on all types of materials.
Durable
Its stability has been proven in a wide range of industrial environments, enabling it to withstand the harshest conditions and highest production cycles. Its rugged design makes this marking solution particularly well-suited for high-paced production.
Model: | TS-90×160K7 |
Controller: | Embedded software and touchscreen |
Marking Window: | 90×160mm |
Marking Speed: | 1-180 characters per minute (5mm height) |
Marking Depth: | 0.1-1.0mm (depending on material) |
Marking Content: | Numerals 0–9, letters A–Z, Chinese characters, common graphic symbols, QR codes, logos, etc. |
Power Supply Method: | 110–240V ±10%, 50Hz |
Power Rating: | <50W |
Machine Dimensions: | L332 × W480 × H870mm (including handwheel) |
Machine Weight: | 33.7kg, 34.5kg including accessories |
Air Supply Pressure: | 0.3–0.7MPa |
